SPECIFICATIONS
| | Model | MF756CX | | Print | Printing Method
Colour Laser Beam Printing
Print Speed
A4
33 / 33 ppm (Mono / Colour)
Letter
35 / 35 ppm (Mono / Colour)
2-Sided
29 / 29 ppm (Mono / Colour)
Print Resolution
600 x 600 dpi
Print Quality with Image Refinement Technology
1,200 (eq.) x 1,200 dpi (eq.)
Warm-Up Time (From Power On)
14 sec or less
First Print Out Time (FPOT) (Approx.)
A4
7.1 / 7.1 sec (Mono / Colour)
Letter
7.0 / 7.0 sec (Mono / Colour)
Recovery Time (From Sleep Mode)
5.3 sec or less
Print Language
UFR II, PCL 6, Adobe® PostScript® 3™
Auto Duplex Print
Yes
Print Margins
Top/Bottom/Left/Right Margin: 5 mm
Top/Bottom/Left/Right Margin: 10 mm (Envelope)
Supported File Format for USB Direct Print
JPEG, TIFF, PDF | | Copy | Copy Speed A4
A4
33 / 33 ppm (Mono / Colour)
Letter
35 / 35 ppm (Mono / Colour)
Copy Resolution
600 x 600 dpi
First Copy Time (FCOT) (Approx.)
ADF
A4
7.6 / 8.8 sec (Mono / Colour)
Letter
7.4 / 8.6 sec (Mono / Colour)
Maximum Number of Copies
Up to 999 copies
Reduce/Enlargement
25 - 400% in 1% increments
Copy Features
Frame Erase, Collate, 2 on 1, 4 on 1, ID Card Copy, Passport Copy | | Scan | Scan Resolution
Optical
Platen glass: up to 600 x 600 dpi
Feeder: up to 300 x 300 dpi
Driver Enhanced
Up to 9,600 x 9,600 dpi
Scan Type
Colour Contact Image Sensor
Maximum Scan Size
Platen glass
Up to 216.0 x 297 mm
Feeder
Up to 216.0 x 355.6 mm
Scan Speed *1
1-Sided: 50 ipm (mono), 40 ipm (colour)
2-Sided: 100 ipm (mono), 80 ipm (colour)
Colour Depth
24-bit
Pull Scan
Yes, USB and Network
Push Scan (Scan To PC) with MF Scan Utility
Yes, USB and Network
Scan To USB (via USB Host 2.0)
Yes
Scan To Cloud
MF Scan Utility
Scan Driver Compatibility
TWAIN, WIA | | Send | SEND Method
SMB, Email, FTP, iFAX
Colour Mode
Full Colour, Grayscale, Monochrome
Scan Resolution
300 x 600 dpi
File Format
JPEG, TIFF, PDF, Compact PDF, PDF (OCR) | | Fax | Modem Speed
Up to 33.6 Kbps
Fax Resolution
Up to 408 x 392 dpi
Compression Method
MH, MR, MMR, JBIG
Memory Capacity*2
Up to 512 pages
Favourite Dials (In address book)
19 dials
Speed Dial (Coded dials)
Up to 281 dials
Group Dials / Destinations
Max. 299 dials / Max. 299 destinations
Duplex Fax (Transmission)
Yes
Sequential Broadcast
Max. 310 destinations
Receive Mode
Fax Only, Manual, Answering, Fax/Tel Auto Switch
Memory Backup
Permanent fax memory backup (backup with flash memory)
Fax Features
Fax Forwarding, Dual Access, Remote Reception, PC Fax (Transmission only), DRPD, ECM, Auto Redial, Fax Activity Reports, Fax Activity Result Reports, Fax Activity Management Reports
Transmission Time
Approx. 2.6 sec | | Paper Handling | Auto Document Feeder (ADF)
Duplex ADF: 50 sheets (80 g/m2)
Available Paper Size for ADF
A4, B5, A5, A6, Letter, Legal, Statement, Business Card
(min. 48.0 x 85.0 mm to max. 216.0 x 355.6 mm)
Paper Input (Based on 80 g/m2)
Standard Cassette
250 sheets
Multi-Purpose Tray
50 sheets
Optional Paper Feeder
550 sheets
Maximum Paper Input Capacity
850 sheets
Paper Output
150 sheets
Paper Sizes
Standard Cassette
A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal, Envelope (COM10, Monarch, C5, DL)
Custom (min. 98.0 x 148.0 mm to max. 216.0 x 356.0 mm)
Multi-Purpose Tray
A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal, Index Card, Envelope (COM10, Monarch, C5, DL)
Custom (min. 76.0 x 127.0 mm to max. 216.0 x 356.0 mm)
Optional Paper Feeder
A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal
Custom (min. 100.0 x 148.0 mm to max. 216.0 x 356.0 mm)
Available Paper Size for Auto Duplex Print
A4, B5, A5, Letter, Legal, Executive, Foolscap, Indian Legal
Paper Types
Plain, Thick, Coated, Recycled, Colour, Label, Postcard, Envelope
Paper Weight
ADF
50 to 105 g/m2
Standard Cassette / Optional Paper Feeder
60 to 200 g/m2
Multi-Purpose Tray
60 to 200 g/m2 | | Connectivity & Software | Standard Interfaces
Wired
USB 2.0 High Speed, 10Base-T/100Base-TX/1000Base-T
Wireless
Wi-Fi 802.11b/g/n
(Infrastructure mode, WPS, Direct Connection)
Network Protocol
Print
LPD, RAW, WSD-Print (IPv4, IPv6)
Scan
Email, SMB, WSD-Scan(IPv4, IPv6), FTP
TCP/IP Application Services
Bonjour (mDNS), HTTP, HTTPS, POP before SMTP (IPv4, IPv6), DHCP, ARP+PING, Auto IP, WINS (IPv4), DHCPv6 (IPv6)
Management
SNMPv1, SNMPv3 (IPv4, IPv6)
Network Security
Wired
IP/Mac address filtering, HTTPS, SNMPv3, IEEE802.1x, IPSEC, TLS 1.3
Wireless
Infrastructure Mode: WEP (64/128 bit), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA-EAP (AES), WPA2-EAP (AES), IEEE802.1x
Access Point Mode: WPA2-PSK (AES)
Other Features
Department ID, Secure Print, Application Library
Mobile Solution
Canon PRINT Business, Canon Print Service, Apple® AirPrint®, Mopria® Print Service, Microsoft Universal Print
Address Book
LDAP
Compatible Operating Systems*3
Windows®, Windows Server®, Mac® OS, Linux*4
Software Included
Printer driver, Fax driver, Scanner driver, MF Scan Utility, Toner Status
General
Device Memory
1 GB
Display
WVGA Colour LCD 5-inch Touch Screen Display
Dimensions (W x D x H) (Approx.)
425 x 461 x 430 mm
Weight (Approx.)
22.0 kg
Power Consumption (Approx.)
Maximum (Operation)
1,380 W or less
Average (Operation)
700 W
Average (Standby)
24.0 W
Average (Sleep)
1.0 W (USB/Wired/Wireless)
Operating Environment
Temperature
10 - 30°C
Humidity
20% - 80% RH (No condensation)
Power Requirements
AC 220 - 240 V (+/-10%), 50/60 Hz (+/-2 Hz)
Toner Cartridge*5
Standard
Cartridge 069 BK: 2,100 pages (Bundled: 2,100 pages)
Cartridge 069 CMY: 1,900 pages (Bundled: 1,100 pages)
High
Cartridge 069H BK: 7,600 pages
Cartridge 069H CMY: 5,500 pages
Monthly Duty Cycle*6
50,000 pages | | * Prices, Features, Package Content and Specifications are subject to change without prior notification.* |
|
|
