| Model | G2020 | | Print | Ink
Number of Nozzles
Total 1,792 nozzles
Ink Bottles
GI-71 (Pigment Black / Cyan / Magenta / Yellow)
Ink Cartridges
MC-G02 (Maintenance cartridge)
Maximum Printing Resolution
4,800 (horizontal)*1 x 1,200 (vertical) dpi
Print Speed*2
Based on ISO/IEC 24734
Click here for summary report
Click here for Document Print and Copy Speed Measurement Conditions
Document (ESAT/Simplex)
Approx. 9.1 ipm (black) / 5.0 ipm (colour)
Document (FPOT Ready / Simplex)
Approx. 9.0 sec (black) / 16.0 sec (colour)
Photo (4 x 6") (PP-201/Borderless)
Approx. 45 sec
Printable Width
Up to 203.2 mm (8"),
Borderless: Up to 216 mm (8.5")
Printable Area
Borderless Printing*3
Top/Bottom/Left/Right margin: each 0 mm
Bordered Printing
#10 Envelope/DL Envelope:
Top: 8 mm, Bottom: 12.7 mm, Left/Right: 3.4 mm
Envelopes [C5, Monarch (98.4 x 190.5 mm)]
Top margin: 8 mm, Bottom margin: 12.7 mm, Left/Right margin: 5.6 mm
5 x 5" (127 x 127 mm):
Top/Bottom/Left/Right margin: 6 mm
4 x 4" (89 x 89 mm):
Top/Bottom/Left/Right margin: 5mm
LTR/LGL/Foolscap (215 x 330.2 mm)/
B-Oficio (215 x 335 mm):
Top margin: 3 mm, Bottom margin: 5 mm,
Left: 6.4 mm, Right: 6.3 mm
M-Oficio (216 x 341 mm):
Top margin: 3 mm, Bottom margin: 5 mm,
Left/Right margin: 6.4 mm
Legal (215 x 345 mm):
Top margin: 3 mm, Bottom margin: 5 mm,
Left/Right margin: 5.9 mm
Others:
Top margin: 3 mm, Bottom margin: 5 mm,
Left/Right margin: 3.4 mm
Support Media
Rear Tray
Plain Paper (64 - 105 g/m²)
Photo Paper Pro Luster (LU-101)
Photo Paper Plus Glossy II (PP-201/PP-208)
Matte Photo Paper (MP-101)
Double-Sided Matte Paper (MP-101D)
Glossy Photo Paper "Everyday Use" (GP-508)
High Resolution Paper (HR-101N)
Photo Paper Plus Semi-Gloss (SG-201)
Photo Stickers (PS-108/PS-208/PS-808)
Removable Photo Stickers (PS-308R)
Magnetic Photo Paper (PS-508)
Dark Fabric Iron-On Transfers (DF-101)
Light Fabric Iron-On Transfers (LF-101)
Envelope
Paper Size
Rear Tray
A4, A5, A6, B5, LTR, LGL, Executive (184.2 x 266.7 mm), Legal (215 x 345 mm), Foolscap (215.9 x330.2 mm), F4 (215.9 x 330.2 mm), Oficio2 (215.9 x 330.2 mm), B-Oficio (216 x 355 mm), M-Oficio (216 x 341 mm), 4 x 6", 5 x 7", 7 x 10", 8 x 10", Envelopes DL, Envelopes COM10, Envelopes C5, Envelopes Monarch (98.4 x 190.5 mm), Square (3.5 x 3.5”, 5 x 5”), Card Size (91 x 55 mm)
Custom size:
Width: 55 - 216 mm, Length: 89 - 1200 mm
Paper Size (Borderless)*4
A4, LTR, 4x6", 5x7", 7x10", 8x10",
Square (3.5 x 3.5", 5 x 5"), Card Size (91 x 55 mm)
Paper Handling (Maximum Number)
Rear Tray
Plain Paper (A4, 64g/m²) = 100
High Resolution Paper (HR-101N, A4) = 80
Photo Paper Plus Glossy (PP-201, 4 x 6") = 20
Photo Paper Plus Semi-Gloss
(SG-201, 4 x 6”) = 20
Glossy Photo Paper "Everyday Use"
(GP-508, 4 x 6") = 20
Matte Photo Paper (MP-101, 4 x 6") = 20
Paper Weight
Rear Tray
Plain Paper: 64 - 105 g/m²
Canon paper: max paper weight: approx. 275 g/m²
(Photo Paper Plus Glossy II PP-201)
Ink End Sensor
Dot count type
Print Head Alignment
Manual | | Scan | Scanner Type
Flatbed
Scanner Method
CIS (Contact Image Sensor)
Optical Resolution*6
600 x 1,200 dpi
Scanning Bit Depth (Input/Output)
Grayscale
16 bit/8 bit
Colour
RGB each 16 bit/8 bit
Line Scanning Speed*7
Grayscale
1.5 ms/line (300 dpi)
Colour
3.5 ms/line (300 dpi)
Maximum Document Size
Flatbed
A4/LTR (216 x 297 mm) | | Copy | Maximum Document Size
A4/LTR
Compatible Media
Size
A4, A5, A6, B5, LTR, LGL, Executive (184.2 x 266.7 mm), Legal (215 x 345 mm), Foolscap (215.9 x 330.2 mm), B-Oficio (216 x 355 mm), M-Oficio (216 x 341 mm), 4 x 6", 5 x 7", Square (5 x 5"), Card Size (91 x 55 mm)
Type
Plain Paper
Photo Paper Plus Glossy II (PP-201, PP-208)
Photo Paper Pro Luster (LU-101)
Photo Paper Plus Semi-Gloss (SG-201)
Matte Photo Paper (MP-101)
Glossy Photo Paper (GP-508)
Image Quality
3 positions (Economy, Standard, High)
Density Adjustment
9 positions, Auto intensity (AE copy)
Copy Speed*8
Based on ISO/IEC 24734
Click here for summary report
Click here for Document Print and Copy Speed
Measurement Conditions
Document (Colour): (sFCOT/Simplex) / (sESAT/Simplex)
Approx. 28 sec / 2.6 ipm
Multiple Copy
Black & White/Colour
Max. 99 pages | | System Requirements | Windows 10 / 8.1 / 7 SP1
(operation can only be guaranteed on a PC with a pre-installed Windows 7 or later)
macOS 10.12.6 ~ 10.15 | | General Specifications | Operation Panel
Display
2-Line LCD
Language
33 Languages Selectable: Japanese / English / German / French / Italian / Spanish / Dutch / Portuguese / Norwegian / Swedish / Danish / Finnish / Russian / Czech / Hungarian / Polish / Slovene / Turkish / Greek / Simplified Chinese / Traditional Chinese / Korean / Indonesian / Slovakian / Estonian / Latvian / Lithuanian / Ukrainian / Romanian / Bulgarian / Thai / Croatian / Vietnamese
Interface
USB 2.0
Operating Environment*10
Temperature
5 - 35°C
Humidity
10 - 90% RH (no dew condensation)
Recommended Environment*11
Temperature
15 - 30°C
Humidity
10 - 80% RH (no dew condensation)
Storage Environment
Temperature
0 - 40°C
Humidity
5 - 95% RH (no dew condensation)
Quiet Mode
Available
Acoustic Noise (PC Print)
Plain Paper (A4, B/W)*12
Approx. 49.5 dB(A)
Power
AC 100-240 V, 50/60 Hz
Power Consumption
OFF
Approx. 0.2 W
Standby (scanning lamp is off)
USB connection to PC
Approx. 0.6 W
Copying*13
USB connection to PC
Approx. 18 W
Duty Cycle
Up to 3,000 pages/month
Dimension (WxDxH)
Factory Configuration
Approx. 445 x 330 x 167 mm
Output/ADF trays extended
Approx. 445 x 555 x 238 mm
Weight
Approx. 6.4 kg | | Page Yield | Plain Paper (A4 pages)
(ISO/IEC 24712 test file)*14
Standard:
GI-71 PGBK: 6,000
GI-71 C/M/Y: 7,700
Economy*15:
GI-71 PGBK: 7,500
GI-71 C/M/Y: 7,700
Photo Paper (PP-201, 4 x 6")
(ISO/IEC 29103 test file)*14
Standard:
GI-71 PGBK: NA*16
GI-71 C/M/Y: 2,200 |
|
