| Model | G7070 | | Print | Print Head / Ink
Type
Permanent (Replaceable)
Number of Nozzles
Total 1,792 nozzles
Ink Cartridges
GI-70 (Pigment Black / Cyan / Magenta / Yellow)
Maximum Printing Resolution
4800 (horizontal)*1 x 1200 (vertical) dpi
Print Speed*2
Based on ISO/IEC 24734
Click here for summary report
Click here for Document Print and Copy Speed Measurement Conditions
Document (ESAT/Simplex)
Approx. 13.0 ipm (black) / 6.8 ipm (colour)
Document (FPOT Ready / Simplex)
Approx. 9 sec (black) / 14 sec (colour)
Photo (4 x 6") (PP-201/Borderless)
Approx. 45 sec
Printable Width
Up to 203.2 mm (8"), Borderless: Up to 216 mm (8.5")
Printable Area
Borderless Printing*3
Top/Bottom/Right/Left margin: Each 0 mm
Bordered Printing
#10 Envelope/DL Envelope:
Top 8 mm / Bottom 12.7 mm / Right 5.6 mm / Left 5.6 mm
127 x 127 mm:
Top 6 mm / Bottom 6 mm / Right 6 mm / Left 6 mm
89 x 89mm / 4 x 4":
Top 5 mm / Bottom 5 mm / Right 5 mm / Left 5 mm
LTR / LGL:
Top 3 mm / Bottom 5 mm / Right 6.3 mm / Left 6.4 mm
Other:
Top 3 mm / Bottom 5 mm / Right 3.4 mm / Left 3.4 mm
Bordered Auto 2-Sided Printing
Top / Bottom margin: 5 mm
Left / Right margin: 3.4 mm (LTR: Left: 6.4 mm, Right: 6.3 mm)
Support Media
Rear Tray
Plain Paper (64 - 105 g/m²)
Photo Paper Pro Platinum (PT-101)
Photo Paper Pro Luster (LU-101)
Photo Paper Plus Glossy II (PP-201/PP-208)
Matte Photo Paper (MP-101)
Glossy Photo Paper "Everyday Use" (GP-508)
High Resolution Paper (HR-101N)
Photo Paper Plus Semi-Gloss (SG-201)
Photo Stickers (PS-108/PS-208/PS-808)
Removable Photo Stickers (PS-308R)
Magnetic Photo Paper (PS-508)
Envelope
Cassette
Plain Paper (64 - 105 g/m²)
Paper Size
Rear Tray
A4, A5, B5, LTR, LGL, 4 x 6", 5 x 7", 7 x 10", 8 x 10"
Envelopes (DL, COM10), Square (5 x 5", 4 x 4", 89 x 89 mm), Card Size (91 x 55 mm)
[Custom size]
width 55 - 215.9 mm, length 89 - 676 mm
Cassette
A4, A5, B5, LTR
[Custom size]
width 148.0 - 215.9 mm, length 210 - 297 mm
Paper Size (Borderless)*4
A4, LTR, 4 x 6", 5 x 7", 7 x 10", 8 x 10"
Square (5 x 5",4 x 4",89 x 89 mm), Card Size (91 x 55 mm)
Paper Handling (Maximum Number)
Rear Tray
Plain Paper (A4, 64 g/m²) = 100
High Resolution Paper (HR-101N) = 80
Photo Paper: 4 x 6" = 20, 5 x 7" = 10
Cassette
Plain Paper (A4, 64 g/m²) = 250
Support Media for Auto 2-sided printing
Type
Plain Paper
Size
A4, A5, B5, LTR
Paper Weight
Rear Tray
Plain Paper: 64 - 105 g/m²
Canon paper: Max paper weight: Approx. 300 g/m²
(Photo Paper Pro Platinum PT-101)
Cassette
Plain Paper: 64 - 105 g/m²
Ink End Sensor
Electrode type and dot count type combined
Print Head Alignment
Auto/Manual | | Scan | Scanner Type
Flatbed
Scanner Method
CIS (Contact Image Sensor)
Optical Resolution*6
Optical resolution scan is available, only when you use TWAIN Driver.
1200 x 2400 dpi
Scanning Bit Depth (Input/Output)
Grayscale
16 bit/8 bit
Colour
RGB each 16 bit/8 bit
Line Scanning Speed*7
Grayscale
1.5 ms/line (300 dpi)
Colour
3.5 ms/line (300 dpi)
Maximum Document Size
Flatbed
A4/LTR (216 x 297 mm)
ADF | | | Maximum Document Size
Flatbed
A4/LTR (216 x 297mm)
Compatible Media
Size
A4/A5/B5/LTR/LGL/4 x 6"/5 x 7"/
Square (5 x 5")/Card Size (91 x 55 mm)
Type
Plain Paper
Photo Paper Pro Platinum (PT-101)
Photo Paper Pro Luster (LU-101)
Photo Paper Plus Semi-Gloss (SG-201)
Glossy Photo Paper "Everyday Use" (GP-508)
Matte Photo Paper (MP-101)
Photo Paper Plus Glossy II (PP-201)
Photo Paper Plus Glossy II (PP-208)
Image Quality
3 positions (Economy, Standard, High)
Density Adjustment
9 positions, Auto intensity (AE copy)
Copy Speed*8
Based on ISO/IEC 24734
Click here for summary report
Click here for Document Print and Copy Speed
Measurement Conditions
Document (Colour) (sFCOT/Simplex) / (sESAT/Simplex)
Approx. 22 sec / approx. 3.9 ipm
Multiple Copy
Black/Colour:
Max. 99 pages
Fax
Type
Desktop Transceiver (Super G3 / Colour Communication)
Applicable Line
PSTN
Transmission Speed*9
Approx. 3 sec (black) / approx. 1 min (colour)
Fax Resolution
Black
8 pels/mm x 3.85 lines/mm (Standard)
8 pels/mm x 7.7 lines/mm (Fine)
300 dpi x 300 dpi (Extra Fine)
Colour
200 × 200 dpi
Print Size
A4, LTR, LGL
Scanning Width
208 mm (A4), 214 mm (LTR)
Modem Speed
Maximum 33.6 kbps (Automatic fall back)
Compression
Black
MH, MR, MMR
Colour
JPEG
Gradation
Black
256 levels
Colour
24 bit Full colour (RGB each 8 bit)
ECM (Error Correction Mode)
ITU-T T.30 compatible
Automatic Dialling
Group Dialling
Max. 19 locations
Transmission/Reception Memory*10
Approx. 50 pages
PC Fax
Type
Windows / Mac
Destination Number
1 location
Black/Colour
B/W transmission only | | Network | Protocol
SNMP, HTTP, TCP/IP (IPv4/IPv6)
Wired LAN
Network Type
IEEE802.3u (100BASE-TX) / IEEE802.3 (10BASE-T)
Data Rate
10M/100Mbps (auto switchable)
Wireless LAN
Network Type
IEEE802.11n/g/b
Frequency Band
2.4 GHz
Channel*11
1 - 13
Range
Indoor 50 m (depends on the transmission speed and conditions)
Security
WEP64/128 bit
WPA-PSK (TKIP/AES)
WPA2-PSK (TKIP/AES)
Direct Connection (Wireless LAN)
Available | | Printing Solutions | AirPrint
Available
Windows 10 Mobile
Available
Mopria
Available
Google Cloud Print
Available
Canon Print Service
(for Android)
Available
PIXMA Cloud Link
(from smartphone/tablet)
Available
Easy Photo-Print Editor
(for iOS/for Android)
Available
Canon PRINT Inkjet/SELPHY
(for iOS/for Android)
Available | | System Requirements | Windows 10 / 8.1 / 7 SP1
(operation can only be guaranteed on a PC with a pre-installed Windows 7 or later)
OS X 10.11.6
macOS 10.12～ macOS 10.14 | | General | Operation Panel
Display
2-Line LCD
Language
32 Selectable Languages: Japanese / English / German / French / Italian / Spanish / Dutch / Portuguese / Norwegian / Swedish / Danish / Finnish / Russian / Czech / Hungarian / Polish / Slovene / Turkish / Greek / Simplified Chinese / Traditional Chinese / Korean / Indonesian / Slovakian / Estonian / Latvian / Lithuanian / Ukrainian / Romanian / Bulgarian / Thai / Croatian / Vietnamese
Interface
Hi-Speed USB 2.0
PictBridge (Wireless LAN / LAN)
Available
Operating Environment*13
Temperature
5 - 35°C
Humidity
10 - 90% RH (no dew condensation)
Recommended Environment*14
Temperature
15 - 30°C
Humidity
10 - 80% RH (no dew condensation)
Storage Environment
Temperature
0 - 40°C
Humidity
5 - 95% RH (no dew condensation)
Quiet Mode
Available
Acoustic Noise (PC Print)
Plain Paper (A4, B/W)*15
Approx. 47.0 dB(A)
Power
AC 100-240 V, 50/60 Hz
Power Consumption
OFF
Approx. 0.3 W
Standby (scanning lamp is off)
USB connection to PC
Approx. 1.0 W
Standby (all ports connected, scanning lamp is off)
[EU only - for ErP Lot 26 regulation]
Approx. 1.8 W
Time to enter Standby mode [EU only - for ErP Lot 26 regulation]
Approx. 11 min 10 sec.
Copy*16
USB connection to PC
Approx. 15 W
Environment
Regulation
RoHS (EU, China), WEEE (EU)
Duty Cycle
Up to 5,000 pages/month
Dimension (WxDxH)
Factory Configuration
Approx. 403 x 369 x 234 mm
Output/ADF trays extended
Approx. 403 x 701 x 305 mm
Weight
Approx. 9.6 kg | | Page Yield | Plain Paper (A4 pages)
(ISO/IEC 24712 test file)*17
Standard:
GI-70 PGBK: 6,000
GI-70 C/M/Y: 7,700
Economy:
GI-70 PGBK: 8,300
GI-70 C/M/Y: 7,700
Photo Paper PP-201, 4 x 6"
(ISO/IEC 29103 test file)*17
Standard:
GI-70 PGBK: NA
GI-70 C/M/Y: 2,200 | | Prices, Features, Package Content and Specifications are subject to change without prior notification.* |
|
