| Model |
HP Mono Laser Enterprise M507x (1PV88A) Printer |
| Functions |
Functions
Print |
| Printing Specification |
Print speed black (ISO, A4)
Up to 43 ppm13
Print speed duplex (A4)
Up to 34 ipm
First page out black (A4, ready)
As fast as 5.9 sec
Duty cycle (monthly, A4)
Up to 150,000 pages8
Recommended monthly page volume
2,000 to 7,5009
Number of users
5-15 Users
Print technology
Laser
Print quality black (best)
Up to 1200 x 1200 dpi
Processor speed
1.2 GHz
Print languages
HP PCL 6, HP postscript level 3 emulation, native PDF printing (v 1.7), Apple AirPrint™
Display
2.7-in (6.86 cm) QVGA LCD (color graphics)
Print colors
No
Number of print cartridges
1 (black)
Mac compatible
Yes
Printer Management
HP Printer Assistant; HP Device Toolbox; HP Web JetAdmin Software; HP JetAdvantage Security Manager; HP SNMP Proxy Agent; HP WS Pro Proxy Agent; Printer Administrator Resource Kit for HP Universal Print Driver (Driver Configuration Utility - Driver Deployment Utility - Managed Printing Administrator)
Security managementIdentity management: Kerberos authentication; LDAP authentication; 1000 user PIN codes; optional HP and 3rd party advanced authentication solutions (e.g.; badge readers); Network: IPsec/firewall with Certificate; Pre-Shared Key; and Kerberos authentication; Supports WJA-10 IPsec configuration Plug-in; 802.1X authentication (EAP-PEAP; EAP-TLS); SNMPv3; HTTPS; Certificates; Access Control List; Data: Storage Encryption; Encrypted PDF & Email (uses FIPS 140 validated cryptographic libraries from Microsoft); Secure Erase; SSL/TLS (HTTPS); Encrypted Credentials; Device: Security lock slot; USB port disablement; hardware integration pocket for security solutions; Intrusion Detection with Red Balloon Security Technology - Constant in-device monitoring for attacks; SureStart Secure Boot - BIOS Integrity Checking with self-healing capability; Whitelisting - loads only known good code (DLLs, EXEs, ...); Connection Inspector - helps ensure network connections to device are safe, Security management: Compatible with HP JetAdvantage Security Manager, HP Printer Security Plugin for Microsoft SCCM, Device Security Syslog Messages processed and accessable in ArcSight, Splunk, and McAfee(ESM) SIEMs
Fonts and typefaces
105 internal TrueType fonts scalable in HP PCL, 92 internal scalable fonts in HP postscript Level 3 emulation (Euro symbol built-in); 1 internal Unicode Fonts (Andale Mono World Type);2 Internal Windows Vista 8 Fonts (Calibri, Cambria);additional font solutions available via third-party flash memory cards; HP LaserJet Fonts and IPDS Emulation available at Http://www.hp.com/go/laserjetfonts |
| Connectivity |
Mobile printing capability
Apple AirPrint™; Google Cloud Print™; HP ePrint; Mopria™ Certified; ROAM optional for easy printing7
Wireless capability
Optional, enabled with purchase of a wireless hardware accessory. Single band Wireless Station and Wi-Fi Direct functionality available with HP Jetdirect 3000w NFC/Wireless Accessory J8030A, Dual band Wireless Station and Wi-Fi Direct functionality available with HP Jetdirect 3100w BLE/NFC/Wireless Accessory 3JN69A, Dual band Wireless Station functionality available with HP Jetdirect 2900nw Print Server J8031A
Connectivity, standard1 Hi-Speed Device USB 2.0; 2 Hi-Speed USB 2.0 Host; 1 Gigabit Ethernet
Connectivity, optional
Yes, via HP Jetdirect Ethernet embedded print server (standard) which supports: 10Base-T, 100Base-Tx, 1000Base-T; 802.3az (EEE) support on Fast Ethernet and Gig Links; IPsec (standard); 802.11a/b/g/n wireless networking (optional); second Ethernet port (optional).
Minimum System Requirements
2 GB available hard disk space, Internet connection, USB port, Internet browser. For additional OS hardware requirements see microsoft.com
Minimum System Requirements for Macintosh
2 GB available hard drive space, Internet connection or USB port, OS hardware requirements see apple.com;
Compatible Operating Systems
Windows Client OS (32/64 bit), Win10, Win8.1, Win 8 Basic, Win8 Pro, Win8 Enterprise, Win8 Enterprise N, Win7 Starter Edition SP1, UPD Win7 Ultimate, Mobile OS, iOS, Android, Mac, Apple® macOS Sierra v10.12, Apple® macOS High Sierra v10.13, Apple® macOS Mojave v10.14, Discrete PCL6 Printer Driver, For more information on the supported operating systems go to http://support.hp.com, Enter your product name and search, Click on User Guides and enter your product name and search for User Guide, Search for your (Product Name) - User Guide, Search for the Supported Operating Systems section, UPD PCL6 / PS Printer Drivers, Supported Operating systems, For more information on the supported operating systems see http://www.hp.com/go/upd
Compatible Network Operating Systems
Windows Server 2008 R2 64-bit, Windows Server 2008 R2 64-bit (SP1), Windows Server 2012 64-bit, Windows Server 2012 R2 64-bit, Windows Server 2016 64-bit, Failover Cluster 2008 R2, Failover Cluster 2012 R2, Terminal server 2008 R2, Remote Desktop server 2012 R2, Citrix Server 6.5, Citrix XenApp & XenDesktop 7.6, Novell iPrint server, Citrix Ready Kit Certification - Up to Citrix Server 7.18 for more information see http://citrixready.citrix.com, Linux- For more information see http://developers.hp.com/hp-linux-imaging-and-printing, Unix- For more information see http://hp.com/go/unixmodelscripts, UPD PCL6 / PS Printer Drivers-, Supported for Compatible Network Operating systems please see http://hp.com/go/upd |
| Memory Specifications |
Memory
512 MB
Maximum Memory
1.5 GB MAX memory, when Accessory DIMM is installed
Memory Slots1 slot, 90-pin DDR3 Slim DIMM
Internal Storage
Optional, 500 GB minimum encrypted hard disk drive |
| Paper Handing |
Paper handling input, standard
100-sheet multipurpose Tray 1, 550-sheet input tray 2
Paper handling input, optional
Up to 3 optional 550-sheet paper feeders
Input capacity
Up to 650 sheets
Maximum input capacity (sheets)
Up to 2300 sheets
Paper handling output, standard
250-sheet output bin
Output capacity
Up to 250 sheets
Maximum output capacity (sheets)
Up to 250 sheets
Finished output handling
Automatic (standard)
Duplex printing
Manual (driver support provided)
Paper trays, standard
2
Paper trays, maximum
5
Envelope Feeder
No
Media sizes supported
Tray 1: A4, A5, A6, RA4, B5 (JIS), B6 (JIS), 10 x 15 cm, Oficio (216 x 340), 16K, postcards (JIS single and double), envelopes (B5, C5, C6, DL); Tray 2: A4, A5, A6, RA4, B5 (JIS), B6 (JIS), Oficio (216 x 340), 16K, postcards (JIS double); Optional 550-sheet Tray: A4, A5, A6, RA4, B5 (JIS), B6 (JIS), Oficio (216 x 340), 16K, postcards (JIS double); Optional Automatic Duplexer: A4, RA4, Oficio (216 x 340)
Media sizes, customTray 1: 76.2 x 127 to 215.9 x 355.6 mm; Tray 2: 105 x 148 to 215.9 x 355.6 mm; Optional 550-sheet Tray: 105 x 148 to 215.9 x 355.6 mm
Media types
Paper (bond, color, letterhead, plain, preprinted, prepunched, recycled, rough); envelopes; labels; cardstock; transparencies; user-defined
Media weight, supported
Tray 1: 60 to 199 g/m²; Tray 2+: 60 to 120 g/m² |
| Power and Operating Requirement |
Power
Input voltage: 100V to 127V nominal (+/-10%), 50 - 60Hz nominal (+/- 3Hz), 7.5 A; Input voltage: 220V to 240V nominal (+/-10%), 50 - 60Hz nominal (+/- 3Hz), 4 A
Power supply type
Built-in 115V or 220V Power Supply
Power consumption
601 (Active Printing) 7.60 (Ready), 2.61 watts (Sleep), 0.06 watts (Auto-Off), 0.06 watts (Off), Auto Off/Wake on LAN 0.73 Watt3
Typical electricity consumption (TEC) number1.257 kWh/Week (Blue Angel); 1.310 kWh/Week (Energy Star)
Energy efficiency
CECP
ENERGY STAR® certified
No
Operating temperature range
10 to 32.5°C
Recommended operating humidity range
30 to 70% RH |
| Dimensions and Weight |
Minimum dimensions (W x D x H)418 x 376 x 481 mm
Maximum dimensions (W x D x H)418 x 639 x 481 mm
Weight16.34 kg
Package dimensions (W x D x H)671 x 497 x 465 mm
Package weight
22.6 kg
Quantity per pallet15
Pallet dimensions (W x D x H)1200 x 1000 x 2476 mm
Pallet weight299.6 kg |
