QNAP TS-1232PXU-RP-4G 12-Bay NAS Enclosure
QNAP · NAS & Storage

QNAP TS-1232PXU-RP-4G 12-Bay NAS Enclosure

QNAP TS-1232PXU-RP-4G 12-Bay NAS Enclosure - Key Features12 x 2.

Quote on request
✓ Available to order · supplied & installed in Malaysia
Request Quotation WhatsApp Ask a question
Key specifications
Form factor 2U Rackmount
Full specifications ↓

Product details

Key Features

  • 12 x 2.5"/3.5" SATA III Drive Bays
  • 1.7 GHz ARM Cortex-A57 Quad-Core CPU
  • 4GB DDR4 RAM
  • 2 x 2.5GbE RJ45 | 2 x 10GbE SFP+
  • USB 3.2 Gen 1 Type-A
  • RAID 0, 1, 5, 6, 10, 50, 60, JBOD
  • Up to 1946 MB/s Read Speeds
  • Up to 643 MB/s Write Speeds
  • Redundant 250W Power Supplies
  • QTS 4.4.3 Operating System


CPUAnnapurnaLabs Alpine AL324 64-bit ARM® Cortex-A57 4-core 1.7GHz processor
CPU Architecture64-bit ARM
Floating Point Unit
Encryption Engine
System Memory4 GB UDIMM DDR4 (1 x 4 GB)
Maximum Memory16 GB (1 x 16 GB)
Memory Slot1 x UDIMM DDR4
Flash Memory512 MB (Dual boot OS protection)
Drive Bay12 x 3.5-inch SATA 6Gb/s, 3Gb/s
Drive Compatibility3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
Hot-swappable
M.2 SlotOptional via a PCIe adapter
SSD Cache Acceleration Support
2.5 Gigabit Ethernet Port (2.5G/1G/100M)2 (2.5G/1G/100M/10M)
10 Gigabit Ethernet Port2 x 10GbE SFP+
Wake on LAN (WOL)
Only the 2.5GbE port
Jumbo Frame
PCIe Slot1
Slot 1: PCIe Gen 2 x2
PCIe bandwidth limitations will restrict the NAS 10GbE performance.
Card dimensions for PCIe slot：220 x 68.9x 18.76 mm / 8.67 x 2.71 x 0.74 inches.
USB 3.2 Gen 1 port4
Form Factor2U Rackmount
LED IndicatorsHDD 1-12, Status, LAN, Storage expansion
ButtonsPower, Reset
Dimensions (HxWxD)88.6 × 432 × 511 mm
Excludes ear hook and the protruding part of the Power Supply Unit.
Weight (Net)12.94 kg
Weight (Gross)14.94 kg
Operating Temperature0 - 40 °C (32°F - 104°F)
Storage Temperature-20 - 70°C (-4°F - 158°F)
Relative Humidity5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit250W (x2) PSU, 100 - 240V
Power Consumption: Operating Mode, Typical83.57 W
Tested with drives fully populated.
Fan2 x 70mm, 12VDC
System WarningBuzzer
Standard Warranty
Supplied & supported by RYZEN ESOLUTIONS (M) SDN BHD
  • Delivery & professional installation
  • Configuration & migration
  • Manufacturer warranty handling
  • Annual maintenance & managed services (MSP)
