QNAP TS-133 NAS (1 bay ARM 4C 1.8GHz ; 1 x SATA 6Gb/s 3.5"/2.5"; 2GB RAM on-board; 1 x GbE ; 1 x USB3.2 Gen1 and 1 x USB2.0)
Key Features1 x 3.
Quote on request
✓ Available to order · supplied & installed in Malaysia
| Form factor | Tower |
Product details
Key Features
- 1 x 3.5" / 2.5" SATA III Drive Bay
- 1.8 GHz ARM Cortex-A55 Quad-Core CPU
- 2GB RAM
- 1 x Gigabit Ethernet Port
- 1 x USB 3.1 Gen 1 | 1 x USB 2.0
- AES 256-Bit Volume Encryption
- QTS 5.0.0 Operating System
TS-133
| CPU | ARM 4-core Cortex-A55 1.8GHz processor |
| CPU Architecture | 64-bit ARM |
| Floating Point Unit | |
| Encryption Engine | |
| Neural Processing Unit (NPU) | |
| System Memory | 2 GB on board (non-expandable) Note: Reserves some RAM for use as shared graphics memory. |
| Maximum Memory | 2 GB on board (non-expandable) |
| Flash Memory | 4 GB (Dual boot OS protection) |
| Drive Bay | 1 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility | 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
| Gigabit Ethernet Port (RJ45) | 1 |
| Wake on LAN (WOL) | |
| Jumbo Frame | |
| USB 2.0 port | 1 |
| USB 3.2 Gen 1 port | 1 |
| Form Factor | Tower |
| LED Indicators | System Status, LAN, HDD |
| Buttons | Power, Reset |
| Dimensions (HxWxD) | 186 × 66.1 × 157.6 mm |
| Weight (Net) | 0.97 kg |
| Weight (Gross) | 1.27 kg |
| Operating Temperature | 0 - 40 °C (32°F - 104°F) |
| Storage Temperature | -20 - 70°C (-4°F - 158°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit | Minimum 36W Adapter (12VDC), 100-240VAC |
| Power Consumption: HDD Sleep Mode | 2.74 W |
| Power Consumption: Operating Mode, Typical | 7.32 W Tested with drives fully populated. |
| Fan | 1 x 50mm, 12VDC |
| System Warning | Buzzer |
| Standard Warranty | 2 |
