RUIJIE RG-ES126G-P-L UNMANAGED SWITCH, 24 GE POE+ PORT + 2 SFP (NON COMBO)

Product details

Ruijie RG-ES100 Series Switches are the next-generation unmanaged switches for scenarios like CCTV, ELV and small offices. The series is designed for small and medium-sized businesses looking for Plug-n-Play solution.

Ruijie RG-ES100 Series is part of the Ruijie SME networking products. The series consists of 3 switches including one 8-port Gigabit PoE+ models and two 24-port Gigabit PoE+ switch models.

These switches can be deployed with plug-and-play out the box. Moreover, port-isolation and flow-control features can be done with a simple flip with the button on the panel. Also, PoE budget status can be shown directly on port indicators, which helps a lot in trouble-shooting.

Key Features

● 24-port and 8 port Gigabit PoE for CCTV/ELV and other SME scenarios

● One-click button simple management beyond Plug-n-Play

● 370W and 180W PoE budget choices on 24-port models

● All 8/24 ports are PoE/PoE+ capable, feel free to choose any ports

● 3 year warranty free of charge

Specifications

Ports

10/100/1000BASE-T: 24

Auto MDI/MDI-X: Yes

1000M SFP: 2

Power over Ethernet

PoE: Yes

PoE/PoE+ enabled Ports: 24

PoE power budget: 370W

Physical

Dimensions(WxDxH): 440x 292 x43.6

Unit weight: 4.2kg

Surge protection: 4KV

Power supply

Type: Internal

Input frequency: 50/60Hz

Input voltage: AC 100~240V

Cooling: Fan

RoHS: Yes

Operating temperature: 0 ℃ ~ 40 ℃

Storage temperature: -40 ℃ ~ 70 ℃

Operating humidity: 5%~90% RH

Storage humidity: 5%~95% RH

Warranty: 3-Year Warranty Free of Charge

Package contents: Ruijie RG-ES100 Series Switch, Power Cord, Mounting Kit, Quick Start Guide

Performance

Switching capacity: 52Gbps

Forwarding rate: 39Mpps
