Synology DiskStation DS420j NAS Server (4 Bay, Dual Core 1.4GHz, 1GB DDR4, 20.6 dB)
Key Features4 x 3.
MYR 1,599.00
reference price — project pricing on quotation
✓ Available to order · supplied & installed in Malaysia
| Form factor | Tower |
| Drive bays | 4 |
| CPU | Realtek RTD1296CPU Quantity1CPU Architecture64-bitCPU Freque |
| RAM (installed/max) | 1 GB DDR4 non-ECCNotesSynology reserves |
| Network ports | RJ-45 1GbE LAN |
Product details
Key Features
| ||
|---|---|---|
CPU | ||
| CPU Model | Realtek RTD1296 | |
| CPU Quantity | 1 | |
| CPU Architecture | 64-bit | |
| CPU Frequency | 4-core 1.4 GHz | |
| Hardware Encryption Engine | ✓ | |
Memory | ||
| System Memory | 1 GB DDR4 non-ECC | |
| Notes | Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance. | |
Storage | ||
| Drive Bays | 4 | |
| Compatible Drive Type* (See all supported drives) |
| |
| Hot Swappable Drive* | - | |
| Notes | "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay. | |
External Ports | ||
| RJ-45 1GbE LAN Port | 1 | |
| USB 3.2 Gen 1 Port* | 2 | |
| Notes | The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019. | |
File System | ||
| Internal Drives |
| |
| External Drives |
| |
| Notes | exFAT Access can be installed for free from Package Center in DSM 7.0. In DSM 6.2 or earlier versions, exFAT Access needs to be purchased in Package Center. | |
Appearance | ||
| Size (Height x Width x Depth) | 184 mm x 168 mm x 230 mm | |
| Weight | 2.21 kg | |
Others | ||
| System Fan | 80 mm x 80 mm x 2 pcs | |
| Fan Speed Mode |
| |
| Brightness Adjustable Front LED Indicators | ✓ | |
| Power Recovery | ✓ | |
| Noise Level* | 20.6 dB(A) | |
| Scheduled Power On / Off | ✓ | |
| Wake on LAN / WAN | ✓ | |
| Power Supply Unit / Adapter | 90 W | |
| AC Input Power Voltage | 100V to 240V AC | |
| Power Frequency | 50/60 Hz, Single Phase | |
| Power Consumption | 21.71 W (Access) 7.88 W (HDD Hibernation) | |
| British Thermal Unit | 74.08 BTU/hr (Access) 26.89 BTU/hr (HDD Hibernation) | |
| Notes |
| |
Temperature | ||
| Operating Temperature | 0°C to 40°C (32°F to 104°F) | |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) | |
| Relative Humidity | 5% to 95% RH | |
Certification | ||
| ||
Warranty | ||
| 2-year hardware warranty, extendable to 4 years with Extended Warranty Plus | ||
| Notes |
| |
Environment | ||
| RoHS Compliant | ||
Packaging Content | ||
| ||
Optional Accessories | ||
| ||
Supplied & supported by RYZEN ESOLUTIONS (M) SDN BHD
- Delivery & professional installation
- Configuration & migration
- Manufacturer warranty handling
- Annual maintenance & managed services (MSP)
Need help choosing?
Talk to the engineers who install this equipment — free sizing advice, no obligation.
Specifications
| Compute Specs | |
|---|---|
| Form factor | Tower |
| NAS Specs | |
|---|---|
| Drive bays | 4 |
| CPU | Realtek RTD1296CPU Quantity1CPU Architecture64-bitCPU Freque |
| RAM (installed/max) | 1 GB DDR4 non-ECCNotesSynology reserves |
| Network ports | RJ-45 1GbE LAN |
| Drives included | No |
