Synology RackStation RS822RP+ 4-Bay 3.5" SATA HDD NAS

Name: Synology RackStation RS822RP+ 4-Bay 3.5" SATA HDD NAS
Brand: Synology
SKU: PRD-202607-5430

Synology RackStation RS822RP+ 4-Bay 3.5" SATA HDD NAS - CPUCPU ModelAMD Ryzen V1500BCPU Quantity1CPU Architecture64-bitCPU Frequency4-core 2.

Quote on request

✓ Available to order · supplied & installed in Malaysia

Request Quotation WhatsApp Ask a question

Key specifications
Form factor	Rackmount

Full specifications ↓

Product details


CPU
CPU Model	AMD Ryzen V1500B
CPU Quantity	1
CPU Architecture	64-bit
CPU Frequency	4-core 2.2 GHz
Hardware Encryption Engine (AES-NI)	✓
Memory
System Memory	2 GB DDR4 ECC SODIMM
Memory Module Pre-installed	2 GB (2 GB x 1)
Total Memory Slots	2
Maximum Memory Capacity	32 GB (16 GB x 2)
Notes	Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance. Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion. For more information about the recommended memory configurations, please check the Hardware Installation Guide of your Synology product.
Storage
Drive Bays	4
Maximum Drive Bays with Expansion Unit	8 (RX418 x 1)
Compatible Drive Type* (See all supported drives)	3.5" SATA HDD 2.5" SATA SSD
Hot Swappable Drive*	✓
Notes	"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay. The maximum raw capacity is not limited by the maximum single volume size. Synology NAS models may utilize capacities over the maximum single volume size as long as each volume created is below the limit. (Learn more)
External Ports
RJ-45 1GbE LAN Port*	4 (with Link Aggregation / Failover support)
USB 3.2 Gen 1 Port*	2
eSATA Port	1
Notes	This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes. The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
PCIe
PCIe Expansion	1 x Gen3 x8 slot (x4 link)
File System
Internal Drives	Btrfs EXT4
External Drives	Btrfs EXT4 EXT3 FAT NTFS HFS+ exFAT
Appearance
Form Factor (RU)	1U
Size (Height x Width x Depth)	RS822+ :44 mm x 480 mm x 492.6 mmRS822RP+ :44 mm x 480 mm x 518.6 mm
Weight	RS822+ :6.4 kgRS822RP+ :8.0 kg
Rack Installation Support*	4-post 19" rack (Synology Rail Kit - RKM114/RKS-02)
Notes	The rail kit is sold separately
Others
System Fan	RS822+ :40 mm x 40 mm x 3 pcsRS822RP+ :40 mm x 40 mm x 2 pcs
Fan Speed Mode	Full-Speed Mode Cool Mode Quiet Mode
Power Recovery	✓
Noise Level*	RS822+ :27.4 dB(A)RS822RP+ :38.8 dB(A)
Scheduled Power On / Off	✓
Wake on LAN / WAN	✓
Power Supply Unit / Adapter	150 W
Redundant Power Supply	RS822+ :-RS822RP+ :✓
AC Input Power Voltage	100 V to 240 V AC
Power Frequency	50/60 Hz, Single Phase
Power Consumption	47.69 W (Access) 16.7 W (HDD Hibernation)
British Thermal Unit	162.83 BTU/hr (Access) 57.02 BTU/hr (HDD Hibernation)
Notes	For more information on how power consumption is measured, refer to this article. Noise testing was conducted with the Synology system fully installed with Synology SATA HDDs and in an idle stae. Two G.R.A.S. Type 40AE microphones are placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
Temperature
Operating Temperature	0°C to 35°C (32°F to 95°F)
Storage Temperature	-20°C to 60°C (-5°F to 140°F)
Relative Humidity	5% to 95% RH
Certification
FCC CE BSMI VCCI RCM UKCA EAC CCC KC UL
Warranty
3-year hardware warranty, extendable to 5 years with EW202
Notes	Availability varies by region. Before purchasing, please visit the official web pages of EW201/202 and Extended Warranty Plus for a list of eligible regions. The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
RoHS Compliant
Packaging Content
RS822+ : Main Unit X 1 Accessory Pack X 1 AC Power Cord X 1 Quick Installation Guide X 1 RS822RP+ : Main Unit X 1 Accessory Pack X 1 AC Power Cord X 2 Quick Installation Guide X 1
Optional Accessories
DDR4 ECC SODIMM: D4ES02-4G/D4ES02-8G/D4ES01-16G Expansion Units: RX418 3.5" SATA HDD: HAT5300 2.5" SATA SSD: SAT5210 M.2 SSD & 10GbE Combo Adapter Card: E10M20-T1 M.2 SSD Adapter Card: M2D20 25GbE Network Interface Card: E25G21-F2 10GbE Network Interface Card: E10G21-F2/E10G18-T2/E10G18-T1 Rail Kit Sliding: RKS-02 Rail Kit Mounted: RKM114* VisualStation: VS360HD Surveillance Device License Pack
Notes	Certain items may not be available in your location. Please contact your local distributors for more information. All memory modules will operate at the maximum frequency specified by the CPU manufacturer.
