Synology UC3200 12-Bay 3.5" SATA HDD NAS
Key Features192TB Storage Capacity12 x 2.
Quote on request
✓ Available to order · supplied & installed in Malaysia
| Form factor | Rackmount |
Product details
- Key Features
- 192TB Storage Capacity
- 12 x 2.5"/3.5" SAS Drive Bays
- 2 x Controller Modules
- 2 x 2.4 GHz Intel Xeon D-1521 Quad-Core
- 2 x 8GB DDR4 RAM
- 2 x GbE & 1 x 10 GbE Port Per Controller
- RAID 0, 1, 5, 6, 10, JBOD, F1
- AES-NI Hardware Encryption
Controller | ||
|---|---|---|
| Number of Controller Module | 2 | |
CPU | ||
| CPU Model | Intel Xeon D-1521 | |
| CPU Quantity | 1 (per controller) | |
| CPU Architecture | 64-bit | |
| CPU Frequency | 4-core 2.4 (base) / 2.7 (turbo) GHz | |
| Hardware Encryption Engine (AES-NI) | ✓ | |
Memory | ||
| System Memory | 8 GB DDR4 ECC UDIMM (per controller) | |
| Memory Module Pre-installed | 8 GB (8 GB x 1) (per controller) | |
| Total Memory Slots | 4 (per controller) | |
| Maximum Memory Capacity | 64 GB (16 GB x 4) (per controller) | |
| Notes |
| |
Storage | ||
| Drive Bays | 12 | |
| Maximum Drive Bays with Expansion Unit | 36 (RXD1219sas x 2) | |
| Compatible Drive Type* (See all supported drives) |
| |
| Maximum Single Volume Size* | 108 TB | |
| Hot Swappable Drive | ✓ | |
| Notes |
| |
External Ports | ||
| RJ-45 1GbE LAN Port | 2 (with Link Aggregation / Failover support) (per controller) | |
| RJ-45 10GbE LAN Port | 1 (per controller) | |
PCIe | ||
| PCIe Expansion | 1 x Gen3 x8 slot (x8 link) (per controller) | |
File System | ||
| Internal Drives | Btrfs | |
Appearance | ||
| Size (Height x Width x Depth) | 88 mm x 430.5 mm x 692 mm | |
| Size (Height x Width x Depth) (with server ears) | 88 mm x 482 mm x 724 mm | |
| Weight | 19.7 kg | |
| Rack Installation Support* | 4-post 19" rack (Synology Rail Kit - RKS-02) | |
| Notes | The rail kit is sold separately | |
Others | ||
| System Fan | 60 mm x 60 mm x 2 (per controller) | |
| Fan Speed Mode |
| |
| Easy Replacement System Fan | ✓ | |
| Power Recovery | ✓ | |
| Noise Level* | 51.3 dB(A) | |
| Power Supply Unit / Adapter | 500W | |
| Redundant Power Supply | ✓ | |
| AC Input Power Voltage | 100 V to 240 V AC | |
| Power Frequency | 50/60Hz, Single Phase | |
| Power Consumption* | 417.48 W (Access) | |
| British Thermal Unit | 1425.45 BTU/hr (Access) | |
| Notes |
| |
Temperature | ||
| Operating Temperature | 0°C to 35°C (32°F to 95°F) | |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) | |
| Relative Humidity | 5% to 95% RH | |
Certification | ||
| ||
Warranty | ||
| 5 Years | ||
| Notes | The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more) | |
Environment | ||
| RoHS Compliant | ||
Packaging Content | ||
| ||
Optional Accessories | ||
| Notes | All memory modules will operate at the maximum frequency specified by the CPU manufacturer. | |
Supplied & supported by RYZEN ESOLUTIONS (M) SDN BHD
- Delivery & professional installation
- Configuration & migration
- Manufacturer warranty handling
- Annual maintenance & managed services (MSP)
Need help choosing?
Talk to the engineers who install this equipment — free sizing advice, no obligation.
Specifications
| Compute Specs | |
|---|---|
| Form factor | Rackmount |
Your research
You recently viewed
Frequently asked questions
How much does the Synology UC3200 12-Bay 3.5" SATA HDD NAS cost?
This product is quoted per project. Send us your requirements and we will prepare a quotation.
Is this product available in Malaysia?
Yes — available to order. Supplied and installed nationwide by RYZEN ESOLUTIONS (M) SDN BHD.
Who manufactures the Synology UC3200 12-Bay 3.5" SATA HDD NAS?
It is manufactured by Synology. We supply genuine units with manufacturer warranty.
Do you provide installation and support?
Yes — we design, install, configure and support this product as part of a complete solution. Ask us about maintenance packages.
