Ubiquiti UF-NANO | ONT | UFiber, 1x GPON, 1x RJ45 1000Mb/s
Ubiquiti UF-NANO | ONT | UFiber, 1x GPON, 1x RJ45 1000Mb/s -
Quote on request
✓ Available to order · supplied & installed in Malaysia
Product details
- High-Performance GPON CPE
- Up to 2.4 Gbps Downstream and 1.2 Gbps Upstream
- Supports up to 20 km GPON Links
- Powerful Layer 2/3 Management Features
- GPON WAN Port
- RJ45 Gigabit LAN Port
- SC/APC Fiber Connector
Featuring an informational LED display, the UFiber Nano G is a robust, high‑performance GPON CPE housed in a sophisticated design. It is powered by 24V passive PoE.
Features:
| UFiber Nano G | |
|---|---|
| Dimensions | 77 x 77 x 28 mm (3.03 x 3.03 x 1.1") |
| Weight | 110 g (3.88 oz) |
| Networking Interfaces | (1) SC/APC, GPON WAN (1) RJ45, Ethernet LAN |
| Networking Interface Speeds | (1) GPON WAN, ITU G.984, 2.488 Gbps Downstream, 1.244 Gbps Upstream (1) GbE LAN, 10/100/1000 Mbps |
| Management Interface | In-Band Ethernet/PON |
| Normal Optical Power Range | TX (Class B+): 1.5 to 5 dBm RX: -8 to -28 dBm |
| Power Method | 24V Passive PoE (Pins 4, 5+; 7, 8-) Dying Gasp Support |
| Power Supply | PoE Adapter: 24V, 0.3A |
| Max. Power Consumption | 7W |
| Supported Voltage Range | 20 to 28V |
| Processor Specs | MIPS-32, 240 MHz |
| Memory Information | 128 MB DDR3 |
| Buttons | (1) Display Information (1) Reset |
| Operating Temperature | -10 to 45° C (14 to 113° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Certifications | CE, FCC, IC |
