Request Quotation
APC Smart-UPS, Line Interactive, 2200VA, Tower, 230V, 8x IEC C13+1x IEC C19 outlets, SmartSlot, AVR, LCD (SMT2200I)
APC · UPS

APC Smart-UPS, Line Interactive, 2200VA, Tower, 230V, 8x IEC C13+1x IEC C19 outlets, SmartSlot, AVR, LCD (SMT2200I)

APC Smart-UPS, Line Interactive, 2200VA, Tower, 230V, 8x IEC C13+1x IEC C19 outlets, SmartSlot, AVR, LCD (SMT2200I) - SpecificationsOverview

Quote on request
✓ Available to order · supplied & installed in Malaysia
Request Quotation WhatsApp Ask a question
Key specifications
Capacity 2200VA VA
Full specifications ↓

Product details

Specifications

Overview
PresentationIntelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
Lead timeUsually in Stock

Main
Main Input Voltage230 V
Other Input Voltage220 V
240 V
Main Output Voltage230 V
Rated power in W1980 W
Rated power in VA2200 VA
Input Connection TypeIEC 320 C20
Schuko CEE 7 / EU1-16P
BS1363A British
output connection type8 IEC 320 C13
2 IEC Jumpers
1 IEC 320 C19
Number of rack unit0U
Number of cables1
Battery typeLead-acid battery
Provided equipmentUSB cable
Documentation CD
Smart UPS signalling RS-232 cable

Batteries & Runtime
Additional informationConfigurable for 220 : 230 or 240 nominal output voltage
Extended runtime0
Number of battery filled slots0
Number of battery free slots0
Battery recharge time3 h
Number of battery replacement quantity1
Battery life3…5 year(s)
Replacement batteryRBC55
action_new_window
Battery charger power260 W rated

General
Number of power module filled slots0
Number of power module free slots0
RedundantNo

Physical
ColourBlack
height43.5 cm
Width19.7 cm
Depth54.4 cm
Net weight48.8 kg
Mounting locationFront
Mounting preferenceNo preference
Mounting modeNot rack-mountable
Two post mountable0
USB compatibleYes

Input
Input voltage limits151...302 V adjustable
160...286 V
Network frequency50/60 Hz +/- 3 Hz auto-sensing

Output
Harmonic distortionLess than 5 % at full load
Maximum configurable power in VA2200 VA
Maximum configurable power in W1980 W
Transfer time6 ms typical : 10 ms maximum
UPS typeLine interactive
Wave typeSine wave
Output frequency47...53 Hz for 50 Hz nominal sync to mains
57...63 Hz for 60 Hz nominal sync to mains

Conformance
product certificationsCE
EAC
RCM
VDE
StandardsEN/IEC 62040-1:2019/A11:2021
EN/IEC 62040-2:2006/AC:2006
EN/IEC 62040-2:2018

Environmental
Acoustic level45 dBA
Heat dissipation275 Btu/h
Operating altitude0...10000 ft
ambient air temperature for operation0…40 °C
Ambient air temperature for storage-15…45 °C
Storage altitude0.00…15240.00 m
IP degree of protectionIP20
Relative humidity0…95 %
Storage Relative Humidity0…95 %

Communications & Management
control panelMultifunction LCD status and control console
Emergency power offYes
Free slots1
AlarmAlarm when on battery : distinctive low battery alarm : configurable delays

Surge Protection and Filtering
Surge energy rate365 J
Noise suppressionFull time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449

Packing Units
Unit Type of Package 1PCE
Number of Units in Package 11
Package 1 Height69.900 cm
Package 1 Width76.200 cm
Package 1 Length38.100 cm
Package 1 Weight61.900 kg
Unit Type of Package 2P12
Number of Units in Package 23
Package 2 Height
Supplied & supported by RYZEN ESOLUTIONS (M) SDN BHD
  • Delivery & professional installation
  • Configuration & migration
  • Manufacturer warranty handling
  • Annual maintenance & managed services (MSP)
Need help choosing?

Talk to the engineers who install this equipment — free sizing advice, no obligation.

Specifications

UPS Specs
Capacity2200VA VA
