QNAP TS-432PXU-RP-2G 1U 4-Bay Arm-Based NAS
QNAP TS-432PXU-RP-2G 1U 4-Bay Arm-Based NAS - Key FeaturesTwo 10GbE SFP+ and Two 2.
Quote on request
✓ Available to order · supplied & installed in Malaysia
| Form factor | 1U Rackmount |
Product details
Key Features
- Two 10GbE SFP+ and Two 2.5 GbE RJ45 Network Ports
- Hybrid Backup Syncs Data to Other NAS Servers
- Snapshots Record System Status and Data
- Compatible With QNAP TR RAID Expansion Enclosures or JBOD
| CPU | AnnapurnaLabs Alpine AL324 64-bit ARM® Cortex-A57 4-core 1.7GHz processor | ||||
| CPU Architecture | 64-bit ARM | ||||
| Floating Point Unit | |||||
| Encryption Engine | |||||
| System Memory | 2 GB UDIMM DDR4 (1 x 2 GB) | ||||
| Maximum Memory | 16 GB (1 x 16 GB) | ||||
| Memory Slot | 1 x UDIMM DDR4 | ||||
| Flash Memory | 512 MB (Dual boot OS protection) | ||||
| Drive Bay | 4 x 3.5" SATA 6Gb/s, 3Gb/s | ||||
| Drive Compatibility | 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives | ||||
| Hot-swappable | |||||
| M.2 Slot | Optional via a PCIe adapter | ||||
| SSD Cache Acceleration Support | |||||
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) | 2 (2.5G/1G/100M/10M) | ||||
| 10 Gigabit Ethernet Port | 2 x 10GbE SFP+ | ||||
| Wake on LAN (WOL) | Only the 2.5GbE port | ||||
| Jumbo Frame | |||||
| PCIe Slot | 1 Slot 1: PCIe Gen 2 x2 PCIe bandwidth limitations will restrict the NAS 10GbE performance. Card dimensions for PCIe slot：210 x 68.9x 18.76 mm / 8.27 x 2.71 x 0.74 inches. | ||||
| USB 3.2 Gen 1 port | 4 | ||||
| Form Factor | 1U Rackmount | ||||
| LED Indicators | HDD 1-4, Status, LAN, Storage expansion | ||||
| Buttons | Power, Reset | ||||
| Dimensions (HxWxD) | 43.3 × 430 × 479 mm Excludes ear hook and the protruding part of the Power Supply Unit. | ||||
| Weight (Net) | 9.08 kg | ||||
| Weight (Gross) | 11.03 kg | ||||
| Operating Temperature | 0 - 40 °C (32°F - 104°F) | ||||
| Storage Temperature | -20 - 70°C (-4°F - 158°F) | ||||
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) | ||||
| Power Supply Unit | 250W (x2) PSU, 100 - 240V | ||||
| Power Consumption: Operating Mode, Typical | 53.343 W Tested with drives fully populated. | ||||
| Fan | 2 x 40mm, 12VDC | ||||
| System Warning | Buzzer | ||||
| Standard Warranty |
