Ubiquiti USW-Lite-16-PoE Layer 2, PoE switch with (16) GbE RJ45 ports, including (8) 802.3at PoE+ ports
Buy Ubiquiti USW-Lite-16-PoE Layer 2, PoE switch with (16) GbE RJ45 ports, including (8) 802.3at PoE+ ports, Ubiquiti from Printer Bullet - Everything for offic...
- Genuine unit through the authorised channel — manufacturer warranty
- Itemised quotation within 1 working day, B2B invoicing
- Delivery nationwide — installation available for enterprise gear
| Ports | 16 GbE RJ45 ports |
| PoE Ports | 8 x 802.3at PoE+ |
| Total PoE Supply | 45W |
| Line Rate | 16 Gbps |
| Power Consumption | 15W |
Product details
- (8) GbE, 802.3at PoE+ RJ45 ports
- (8) GbE RJ45 ports
- 45W total PoE supply
- Fanless, silent cooling
- Wall-mountable (kit included)
The Switch Lite 16 PoE (USW Lite 16 PoE) is a fully managed switch with (16) GbE RJ45 ports, including (8) 802.3at PoE+ ports, and a 45W total PoE supply for your UAP access points and other PoE devices. The USW Lite 16 PoE also offers an extensive suite of Layer 2 switching protocols, and can be monitored or configured from anywhere with the powerful, intuitive UAP Network web application and mobile app.
Features:
Managed with the UAP Network application: Version 5.13.5 and later
| Mechanical | |
|---|---|
| Dimensions | 191.7 x 185 x 43.7 mm (7.55 x 7.28 x 1.72") |
| Weight | 1.2 kg (2.65 lb) |
| Hardware | |
| Total Non-Blocking Line Rate | 16 Gbps |
| Max. Power Consumption | 15W |
| Power Method | Universal AC Input: 100-240VAC |
| Power Supply | Internal 60W AC/DC Power Supply |
| Networking Interfaces | (16) 10/100/1000 Mbps Ethernet RJ45 |
| PoE Interfaces | (8) PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-) |
| Mangement Interface | Ethernet In-Band |
| Max PoE+ Wattage per Port by PSE | 30W |
| Modes | SMB Layer 2 PoE Gigabit Ethernet Switch |
| Operating Temperature | -15 to 40° C (5 to 104° F) |
| Operating Humidity | 10 - 90% Noncondensing |
| Certifcations | CE, FCC, IC |
| LED | |
| System | (1) Power, Blue/White Flashing White: Bootup in Progress Flashing Blue: Firmware Upgrading Steady White: Factory Defaults, Awaiting Adoption Steady Blue: Device is Adopted |
| Ethernet | Green: 1G, Amber: 10/100 Mbps |
| PoE | Amber: IEEE 802.3af/at |
- Delivery & professional installation
- Configuration & migration
- Manufacturer warranty handling
- Annual maintenance & managed services (MSP)
Talk to the engineers who install this equipment — free sizing advice, no obligation.
Specifications
| Printing & Imaging Specs | |
|---|---|
| Ports | 16 GbE RJ45 ports |
| PoE Ports | 8 x 802.3at PoE+ |
| Total PoE Supply | 45W |
| Line Rate | 16 Gbps |
| Power Consumption | 15W |
| Power Input | 100-240VAC |
| Operating Temperature | -15 to 40°C |
| Dimensions | 191.7 x 185 x 43.7 mm |
